| SHIP DESIGN | VS 485 MK IIPSV | ||
| CLASSIFICATION | BV Nr: 21737E | ||
| BUILDER | SEVERNAYA YARD ST PETERSBURG, HULL NO 696 | ||
| IMO NUMBER | 9589607 | ||
| PORT OF REGISTRY | NASSAU | ||
| FLAG | Bahamas | ||
| MMSI | 311 070 200 | ||
| DELIVERY | Nov.2011 | ||
| CALL SIGN | C6ZW5 | ||
| OWNER: | SOLVIK SUPPLIER AS N-5384 TORANGSVÅG |
MANAGER: | VESTLAND MANAGEMENT AS N-5384 TORANGSVÅG |
| MAIN DIMENSIONS | CLASS NOTATIONS | ||
| Length O.A | 85,00 M | BV I*HULL*MACH COMF-NOISE 3,COMF-VIB 3,*AUT-UMS (SS), *SYS-NEQ-1 (SS), CLEANSHIPSUPER, ICE, *DYNAPOS AM/AT R, SDS ERN 99.99.99.99 NOFO 2009 Option: Stand-by Vessel (S) NMD Rescue, FiFi I, Deice C |
|
| Length P.P | 77,70 M | ||
| Breadth | 20,0M | ||
| Max Draft | 7,163M | ||
| Gross Tonnage | 4366T | ||
| Net Tonnage | 1813T | ||
| Deadweight | 5 503T | ||
SOLVIK SUPPLIER SPECIFICATIONS
CARGO CAPACITIES NOFO 2009
| MACHINERY AND PROPELLER PLANTS | |
|---|---|
| Main Engines/Generators: | 4 x 1825 kw CAT 3516B-DSG |
| Emergency Generator: | 1 x 223 kw Volvo Penta D9MG |
| Main Propulsion: | 2 x 2300 kw SteerProp SP 35 CRP |
| FWD Azimuth: | 1 x Brunvoll 880 kW |
| FWD Tunnel Thrusters: | 2 x Brunvoll 1000 kW |
| Deck Cargo: | 2 800 Tons |
| Deck Area: | 1004 m2 With snag protection of cargo rail |
| Deck Strength: | 10 Tons/m2 |
| Fuel Oil: | 907, 2 m3, |
| Liquid Mud (SG 2.8): | 703 m3, Agitators in all tanks |
| Brine (SG 2.5): | 418 m3, |
| Base Oil: | 203 m3, |
| Pot Water: | 1007 m3, |
| Drill Water/Ballast: | 2470 m3, |
| Methanol: | 145 m3 |
| Special Product: | 146 m3, |
| Slop: | 186 m3, 2 x 100 m3/hour |
| ORO: | 1803 m3, 8 x 100 m3/hour |
| Cement/Barite/Bentonit: | 440 m3, 2 x 30 m3/hour (segregated in two system) |
| Navigation | |
| DP System: | Kongsberg K Pos DP 2 |
| Joystick System: | Kongsberg C-Joy Constant |
| DP Motion System 1: | Sea Tex MRU 5 |
| Radarscan: | Guidance |
| Fanbeam: | Kongsberg Lazer Mk 4,2 |
| DGPS: | 2 x Kongsberg Seatex |
| Bridge Consoles: | Fwd and both Wings |
| Operation Control Office: | Located on Bridge |
| Autopilot: | Simrad AP 50 |
| Wind Sensor: | 2 x Kongsberg Maritime |
| Radar 1: | Furuno FAR 2137 S |
| Radar 2: | Furuno FCR 2827 Chart Radar |
| Echo Sounder: | Furuno FE 700 |
| Gyro: | 2 x Simrad GC 80 + 1 x Simrad GC 85 |
| Speed Repeater: | Skipper IR 300 |
| VDR: | Furuno VR 3000 |
| GPS: | 2 x Furuno GP 150 |
| Bridge Watch: | KONSBERG MOS33 |
| ECDIS: | Tecdis T 2138 |
| Speed log: | Furuno DS 80 |
| SPEED AND FUEL CONSUMPTION | |
|---|---|
| Full speed: | 15,0 knots 24.0 mt/24hrs |
| Service speed: | 12.5 knots 17,0 mt/24 hrs |
| Economic speed: | 11.0 knots 11,3 mt/24 hrs |
| DP operation: | 5,6 mt/24 hrs at position keeping 1,6m Hs |
| St-by at field: | 2,9 mt/24 hrs at one engine |
| Harbor mode: | 1,4 mt/24 hrs |
| CARGO HANDELING EQUIPMENT | |
| 1 x TTS Marine GPK knuckle crane, SWL 3 tons/13 meter | |
| 1 x TTS Marine GPT telescopic jib, SWL 3 tons/13 meter | |
| 2 x Capstans aft, NDM SWL 8 tons | |
| 6 x Cargo Securing Winches, NDM SWL 3 tons | |
| 2 x Tugger Winch, NDM TU SWL 15 tons | |
| 6 x Reefer points PS/SB 110 V 36A 60 hz | |
| LIFE SAVING EQUIPMENT | |
| Ship Certificate: | 23 persons |
| Life Rafts: | 4 x 25 persons Unitor |
| MOB: | 1 x NOREQ RRB 500 |
| MOB Davit: | 1 x HLT 3500 TTS |
| Survival Suits: | 23 x SOLAS Immersion Suits Survival suits according to rules |
| COMMUNICATION | |
| Navtex: | Furuno NX-700 B |
| Radar Transponder: | 2 x Jotron Tron SART |
| AIS: | Furuno FA 150 |
| EPIRB manual: | Jotron 45 SX |
| EPIRB Free Float: | Jotron Tron 40 S Mk II |
| Radio Station: | SSB, MF, HF, Furuno FS-1570 |
| VHF Portable: | 3 x Jotron Tron TR 20 GMDSS |
| VHF Station: | Furuno FM-8800 S |
| UHF Portable: | 5 x Motorola GP 340 |
| Inmarsat C: | Furuno Felcom 15 |
| Intercom: | Zenitel ACM 144 66/VO |
| Sound System: | Vingtor VSS 111 |
| Emergency: | Vingtor VSP 211 L |
| PA System: | Zenitel VPA 120, 240 and 400 |
| Satellite Communication: | VSAT +4721615635/36/37/38 |
| Mobile Phone: | Nor mobile: +47 95282973 |
| Vessel E-mail: | captain.solvik@vestlandoffshore.no |
| ACCOMMODATION | |
| Outfitted for 23 persons in spacious and comfortable facilities | |
| Single Cabins: | 13 with bathrooms |
| Double Cabins: | 5 with bathrooms |
| Hospital: | 1 Highest standard |
| Office: | 1 fully outfitted |
| Day Room: | 2 comfortable outfitted |
| Gymnasium: | 1 fully outfitted |
| Entertainment: | In Day Rooms and all Cabins |
| Antiroll Tank: | 1 x 440 m3 + 1 x 160 m3 |
